GN 900 Adjustable Slide Units Aluminum


GN 900 Adjustable Slide Units, Aluminum Identification no.: 2 - With adjustable hand lever
Type: H - with handwheel

Identification no.: 2 - With adjustable hand lever
Type: H - with handwheel

GN 900 Adjustable Slide Units, Aluminum Identification no.: 2 - With adjustable hand lever
Type: H - with handwheel

GN 900 Adjustable Slide Units, Aluminum Identification no.: 1 - Without adjustable handle
Type: D - with control knob

GN 900 Adjustable Slide Units, Aluminum Identification no.: 1 - Without adjustable handle
Type: DR - with control knob and digital position indicator GN 954, type AR

GN 900 Adjustable Slide Units, Aluminum Identification no.: 1 - Without adjustable handle
Type: HN - with handwheel and digital position indicator GN 954, Type AN

GN 900 Adjustable Slide Units, Aluminum Identification no.: 2 - With adjustable hand lever
Type: HR - with handwheel and digital position indicator GN 954, Type AR

GN 900 Adjustable Slide Units, Aluminum Identification no.: 2 - With adjustable hand lever
Type: S - Without adjustable spindle and operating element

Standard sheet GN 900 Print this page Construction description and load values

Product description

Information

Adjustable slide units GN 900 can be combined with a range of adaptors to give various axis configurations.

These fastening units and connecting sets (GN 900.1, GN 900.2, GN 900.3) can be clamped to the adjustable slide units in a rapid and simple way.

For fine adjustment there is a scale ring graduated in increments of 0,05 mm, with digital position indicator 0,02 mm.

Specification

Slides / End plates
Aluminum press formed
Anodized, natural color

Guide shafts
Stainless steel

Drive

Lead spindle / Ball bearing
Stainless steel
Lead nut
Plastic

Fixing screws
Stainless steel

Control knob / Scale ring
Aluminum
Black anodized

RoHS

Accessory

Disk Handwheels GN 520.1
Position Indicators GN 954

Technical drawing

GN 900 Adjustable Slide Units, Aluminum sketch

Hide technical drawing

GN 900 Adjustable Slide Units, Aluminum sketch

Article options / Table

Identification no.

1	Without adjustable handle
2	With adjustable hand lever

Type

D	with control knob
H	with handwheel
DN	with control knob and digital position indicator GN 954, type AN
DR	with control knob and digital position indicator GN 954, type AR
HN	with handwheel and digital position indicator GN 954, Type AN
HR	with handwheel and digital position indicator GN 954, Type AR
S	Without adjustable spindle and operating element

Build & Price

Open 3D configurator

Permissible load values of the adjustable slide units GN 900

Show / Hide columns

b	F₁ in N	F₂ * in N	F₃ in N	M₁ in Nm	M₂ in Nm	M₃ in Nm

30	150	40	65	2	2	1
50	300	120	215	4	5	3
80	500	150	365	8	10	6
120	1000	300	700	15	20	12

*F₂ is the max. permissible sliding thrust

MD900_BL-16101-0

Selected Part (How to order)

Part number

Total (net)

358,88 €

plus VAT 68,19 €
gross 427,07 €

In stock

Weight: 0,381 kg

If this article is new in our product range, it may happen that details concerning weight are as yet not listed.
If you do need weight details, please contact our Sales Department!
Phone +49 7723 6507 - 0

RoHS: Yes

This article is RoHS-compliant in application of Annex III., which means it complies with EU Directive 2011/65/EU, including extension (2015/863/EU), for restricting the use of certain hazardous substances in electrical and electronic devices. The Directive regulates the use of hazardous substances in devices and components. The implementation in national law is summarily described with RoHS(Restriction of (the use of certain) hazardous substances).

Customs tariff number

84798997

Please note our order discounts.

With a total value (net) per order:
from 175,00 € -> 10 % discount
from 275,00 € -> 20 % discount
from 375,00 € -> 30 % discount

Surcharge for small volume purchases:
-> 15,00 Euro
for value of goods less than 25,00 €
-> 10,00 Euro
for value of goods from 25,00 to 49,99 €

Quantity

All prices in accordance with our price list No. 56, valid from 1 September 2024, plus VAT only valid for Germany.
