GN 522 Spoked Handwheels Plastic, Bushing Steel


Original design
code: VRTP. / VRTP+I

Type: R - With revolving handle

GN 522 Spoked Handwheels, Plastic, Bushing Steel Type: A - Without handle

Standard sheet GN 522 Print this page Keyways P9 DIN 6885-1 Cross holes GN 110 ISO Fundamental Tolerances Plastic Characteristics

Product description

Information

Elegant design and ergonomic requirements are realised for the spoked handwheels GN 522.

Specification

Wheel body
Plastic, Polypropylene (PP)

Reinforced, shock-resistant
Operating temperature 0 °C to +80 °C
Black, matte finish

Hub bushing
Steel, blackened

Cover
Aluminum

anodized, natural color
self-adhesive

Threaded bushing
Brass

Revolving handle
Plastic, Polyamide (PA)

Black, matte finish
Spindle steel
Zinc plated, blue passivated

RoHS

Accessory

Countersunk Washers GN 184 (for axial fixation)

On request

with mushroom shaped handle GN 597.1

Technical drawing

GN 522 Spoked Handwheels, Plastic, Bushing Steel sketch

Hide technical drawing

Article options / Table

Bore code

B	Without keyway
K	With keyway DIN 6885-1 P9

Type

A	Without handle
R	With revolving handle

Show / Hide columns

d₁	d₂ H7 Bore		d₃	d₄	d₅	b	l₁	l₂	l₃	r	Ø Handle

80	8	10	18	20,5	25	18	17	35	45	29	16
100	10	12	18	20,5	25,5	20	17	37	60	37	18
125	12	14	22	26	31	22	22	44	65	48	22
160	14	16	26	31	40	25	27	51	73	65	23
200	16	20	30	36	48,5	28	34	61	80	84	24
250	20	24	35	44	58	32	38	69	90	105	25
300	20	26	40	52	66	35,5	43	78	90	127	25
375*	26	-	35	70	81	39	43	87	90	160	25

* not available from stock, requires a minimum order quantity

Build & Price

Open 3D configurator

GN 110 Cross holes (special order)

Show / Hide columns

d₁ H7 s H11	d₁ H7 s H11	d₂ H11	d₃	Length l Standard version	Length l Handwheels DIN 950 / GN 949 to Ø 250

6	7	2,5	M 3	4,5	-
8	9	3	M 5	5,5	4,5
10	11	3	M 5	5,5	4,5
12	13	4	M 6	6,5	5,5
14	15	4	M 6	6,5	5,5
16	17	5	M 6	8	7
18	19	5	M 6	8	7
20	21	5	M 6	8	7
22	23	6	M 6	10	9
24	25	6	M 6	10	9
26	27	6	M 6	10	9

The connection between the operating element and the shaft consists very often of a cross pin or a grub screw.
As a result the user is faced with relatively high costs since cross holes on operating elements are in general not readily available.
Components with cross holes to GN 110 are not only offered at very competitive prices but they also save the manufacturer unnecessary drawing work. The geometrical form of some of the operating elements, however, does not lend itself to modification to this particular standard.
The pin hole d₂ H11 is drilled to suit drive spring pins.

The cross hole GN 110 is to be ordered as a separate item in shopping cart step 1 under note.
How to order: Handwheel DIN 950-GG-160-B14-A with cross hole GN 110-QE

Selected Part (How to order)

Part number

Total (net)

10,82 €

plus VAT 2,06 €
gross 12,88 €

In stock

ELESA Code: 78421-R

Description: VRTP.80+I A-8

Weight: 0,098 kg

If this article is new in our product range, it may happen that details concerning weight are as yet not listed.
If you do need weight details, please contact our Sales Department!
Phone +49 7723 6507 - 0

RoHS: Yes

This article is RoHS-compliant in application of Annex III., which means it complies with EU Directive 2011/65/EU, including extension (2015/863/EU), for restricting the use of certain hazardous substances in electrical and electronic devices. The Directive regulates the use of hazardous substances in devices and components. The implementation in national law is summarily described with RoHS(Restriction of (the use of certain) hazardous substances).
